Honda CR-Z 1 CRZ (2010-2016) RHD & LHD

Din: One Din
Display Size: 9"
Operating System: Android
Digital Media Format: Mp3
Digital Media Format: Mp4
Digital Media Format: WMA
Digital Media Format: JPEG
Special Feature: Wifi Function
Special Feature: Support Steering Wheel Control
Special Feature: Support 3G Network
Special Feature: Support 4G Network

NOTE: If you have a factory amplifier and experience humming, you may need to install HI-Low convertors on the Front left and right speakers of the CC3 that output to the amplifier.

NOTE: If you have lane watch, you will require a different harness, you must contact us before purchase to organise.

NOTE: There may be 2 blue amp wires coming from the harness plug, connect one of them to the A port Blue AMP-C. One may not work, so choose the other.

NOTE: If your head unit looks like this and has subwoofer, it is compatible

Vehicle Make: Honda Model: Cr-z Year: 2014

WARNING!!!

NOTE: If using the harness with canbus -

1. Connect Blue AMP to Blue AMP-C

2: Amp output should be turned up if you have no sound. This will allow the factory amp to turn on.

NOTE: If you have the Premium Audio System with factory AMP and subwoofer and connection Blue AMP-C to Blue AMP as above does not give you sound, to turn on the factory amp you may have to connect KEY2 from the main wiring harness to AMP-C on the accessory harness instead.

KEY2 corresponds to pin A21, and AMP-CON matches to pin A18. Please check to see if this is the same case for you

NOTE: The pinouts for the main connector on the CR-Z with navigation and without navigation are found (here)

IMPORTANT: If your head unit looks like this, it is compatible but the standard provided harness will not work with Lanewatch. You must order this harness

Product Information

Shipping & Returns

Honda CR-Z 1 CRZ (2010-2016) RHD & LHD

Name: Honda CR-Z 1 CRZ (2010-2016) RHD & LHD
Brand: T'EYES
SKU: teyes-cc3-for-honda-cr-z-1-crz-2010-2016-right-hand-driver-car-radio-multimedia-video-player-navigation-stereo-gps-android-10-no-2din-2-din-dvd
Availability: InStock

NOTE: If you have a factory amplifier and experience humming, you may need to install HI-Low convertors on the Front left and right speakers of the CC3 that output to the amplifier.

NOTE: If you have lane watch, you will require a different harness, you must contact us before purchase to organise.

NOTE: There may be 2 blue amp wires coming from the harness plug, connect one of them to the A port Blue AMP-C. One may not work, so choose the other.

NOTE: If your head unit looks like this and has subwoofer, it is compatible

WARNING!!!

NOTE: If using the harness with canbus -

1. Connect Blue AMP to Blue AMP-C

2: Amp output should be turned up if you have no sound. This will allow the factory amp to turn on.

NOTE: The pinouts for the main connector on the CR-Z with navigation and without navigation are found (here)

IMPORTANT: If your head unit looks like this, it is compatible but the standard provided harness will not work with Lanewatch. You must order this harness

Select Memory Size

From $285.47

Honda CR-Z 1 CRZ (2010-2016) RHD & LHD—

$285.47

Select Memory Size

From $285.47

Honda CR-Z 1 CRZ (2010-2016) RHD & LHD—

$285.47

Product Information

Shipping & Returns

Description

NOTE: If you have a factory amplifier and experience humming, you may need to install HI-Low convertors on the Front left and right speakers of the CC3 that output to the amplifier.

NOTE: If you have lane watch, you will require a different harness, you must contact us before purchase to organise.

NOTE: There may be 2 blue amp wires coming from the harness plug, connect one of them to the A port Blue AMP-C. One may not work, so choose the other.

NOTE: If your head unit looks like this and has subwoofer, it is compatible

WARNING!!!

NOTE: If using the harness with canbus -

1. Connect Blue AMP to Blue AMP-C

2: Amp output should be turned up if you have no sound. This will allow the factory amp to turn on.

NOTE: The pinouts for the main connector on the CR-Z with navigation and without navigation are found (here)

IMPORTANT: If your head unit looks like this, it is compatible but the standard provided harness will not work with Lanewatch. You must order this harness
